저철분 플로트/틴트 플로트

틴트 플로트 유리
TINTED FLOAT- 태양에너지 흡수
- 일사열 차단기능
- 각종 복합유리의 원판재료로 사용 가능
- 색상
- F Green, H Green, Blue, Eurogrey, PG (black)
- 규격
- 두께: 2 - 12㎜ (5/64" - 7/16")
- 최대크기: 3,300 × 6,500㎜ (130" - 256")
틴트 플로트 유리 상세사양
Thickness (㎜) |
Visible Light (%) |
Solar Direct (%) | g-Value ISO 9050 (AM=1.0) |
Solar Heat Gain Coefficient (SHGC) NFRC 100-2004 |
Shading Coefficient (S.C.) NFRC 100-2004 |
NFRE U-Value W/㎡·K NFRC 100-2004 | European U-Value W/㎡·K (EN 673) |
STC (dB) |
|||
---|---|---|---|---|---|---|---|---|---|---|---|
Transmi ttance |
Reflec tance |
Transmi ttance |
Reflec tance |
Summer | Winter | ||||||
5 | 77 | 7 | 47 | 6 | 0.60 | 0.62 | 0.71 | 5.27 | 5.84 | 5.7 | 30 |
6 | 75 | 7 | 44 | 6 | 0.58 | 0.59 | 0.68 | 5.24 | 5.81 | 5.7 | 31 |
8 | 69 | 7 | 36 | 5 | 0.52 | 0.54 | 0.62 | 5.19 | 5.74 | 5.7 | 33 |
10 | 64 | 6 | 30 | 5 | 0.48 | 0.51 | 0.58 | 5.13 | 5.67 | 5.6 | 34 |
12 | 60 | 6 | 26 | 5 | 0.45 | 0.48 | 0.55 | 5.07 | 5.61 | 5.5 | 36 |
Thickness (㎜) |
Visible Light (%) |
Solar Direct (%) | g-Value ISO 9050 (AM=1.0) |
Solar Heat Gain Coefficient (SHGC) NFRC 100-2004 |
Shading Coefficient (S.C.) NFRC 100-2004 |
NFRE U-Value W/㎡·K NFRC 100-2004 | European U-Value W/㎡·K (EN 673) |
STC (dB) |
|||
---|---|---|---|---|---|---|---|---|---|---|---|
Transmi ttance |
Reflec tance |
Transmi ttance |
Reflec tance |
Summer | Winter | ||||||
6 | 55 | 6 | 45 | 5 | 0.58 | 0.61 | 0.70 | 5.24 | 5.81 | 5.7 | 31 |
8 | 48 | 6 | 38 | 5 | 0.53 | 0.55 | 0.64 | 5.19 | 5.74 | 5.7 | 33 |
Thickness (㎜) |
Visible Light (%) |
Solar Direct (%) | g-Value ISO 9050 (AM=1.0) |
Solar Heat Gain Coefficient (SHGC) NFRC 100-2004 |
Shading Coefficient (S.C.) NFRC 100-2004 |
NFRE U-Value W/㎡·K NFRC 100-2004 | European U-Value W/㎡·K (EN 673) |
STC (dB) |
|||
---|---|---|---|---|---|---|---|---|---|---|---|
Transmi ttance |
Reflec tance |
Transmi ttance |
Reflec tance |
Summer | Winter | ||||||
6 | 74 | 7 | 54 | 6 | 0.64 | 0.66 | 0.76 | 5.24 | 5.81 | 5.7 | 31 |
8 | 69 | 7 | 45 | 6 | 0.58 | 0.61 | 0.70 | 5.19 | 5.74 | 5.7 | 33 |
The above data are calculated by WINDOW 6.3 developed at Lawrence Berkeley National Laboratory, except for having been given clear indication of standards.
The glass performance data will be finalized by the performance data sheet which submitted by SYP Above performance just for design reference.
